Suitable for wooden cabinet door assembly. Easy operation, without input dimensions, automatic induction assembly.
Suitable for wooden cabinet door assembly.
Easy operation, without input dimensions, automatic induction assembly.
High efficiency: pre-assembling and high frequency gluing are divided into two beats, more efficient, a door for one minute.
Saving energy: front end with pre-assembler machine, without manual pre-assembly, to ensure the stability of production efficiency.
Can connect the customer MES/ERP system, achieve code sweeping processing, also can generate production data statistics report. It can provide data support for didital production, achieve multi-specifications customization flexible production.
| Type | CGRZ-2500×1000P | CGRZ-2500×1000 |
| Max. joining size (mm) | 2500×1000 | 2500×1000 |
| Min. joining size (mm) | 1800×600 | 1800×600 |
| Pressurizing mode | Servo motor | Servo motor |
| Size input method | Scan code setting | Automatic induction |
| Overall dimension (mm) | 16000(L)×2300(W)×2200(H) | 16000(L)×2300(W)×2200(H) |
| Weight (t) | 8.3 | 8.3 |
