Main Functions of Edge Banding Machine in Daily Life

Edge banding machine is an important tool in our daily life, so what does it do? The following are the main functions of the edge banding machine.

1. Pre-milling: use double milling cutters to modify the corrugation marks, burrs, or non-vertical phenomenon caused by the cutting saw of the panel saw to achieve better edge sealing effect. It makes the edge strip and the plate fit more closely, and the integrity and aesthetics are better.

2. Gluing and edge banding: Through a special structure, the two sides of the edge banding plate and edge banding material are evenly glued to ensure a stronger adhesion.

3. Head-to-head: through precise linear guide motion, automatic tracking of the master and high-speed high-speed motor cutting structure to ensure a smooth cut surface.

4. Rough repair/fine repair: Both adopt auto-tracking and high-frequency high-speed motor structure to ensure the smoothness of the upper and lower parts of the trimmed plate. It is used to repair and process the excess edge banding material of the upper and lower edges of the plate.

1) Rough repair function: The rough repair knife is a flat knife. In order to deal with the trimming of excess parts when sealing the veneer. Because when sealing the veneer, you can not directly use the R-shaped knife, the veneer is generally 0.4mm thick, if you directly use the knife, it is easy to cause breakage. In addition, a rough repair can also be used for the first flat repair process when sealing PVC and acrylic.

2) Finishing function: The finishing knife is an R-shaped knife. It is mainly used for PVC and acrylic edge banding of panel furniture, preferably 0.8mm thick or more.

5. Profiling tracking: the up and down rounding device can make the end surface of the plate smoother and more beautiful

6. Scraping: Used to eliminate the ripple marks caused by the cutting process of non-linear movement of the trimming, making the upper and lower parts of the plate smoother and cleaner.

7. Polishing: Clean the processed plate with a cotton polishing wheel, and make the edge end surface smoothed by polishing.

8. Slotting: It is used for direct slotting of wardrobe side panels and bottom plates, which reduces the process of panel sawing. It is more convenient and quick; it can also be used for slotting aluminum door edges.
